JBL Eon 712 Professional 12″ Active Speaker w/ Bluetooth
R14,699.00
12-inch Powered PA Speaker with Bluetooth
Launched in 1995, JBL’s best-selling EON family of PAs set the benchmark for how great a powered loudspeaker system can be.
The JBL EON712 12-inch loudspeaker is part of JBL’s new EON700 Series of powered PAs, which represents a major step forward in innovation and technology: JBL engineers used exclusive, state-of-the-art design and measurement techniques to deliver the best-performing loudspeakers in their category, regardless of application.
The EON700 Series leverages the latest acoustic science, transducer designs, cabinet materials and advanced DSP and control technologies to deliver extraordinary performance in a fully professional, highly flexible, easy to use, portable system.
With four models available, including the 10-inch EON710, the 12-inch EON712 and the 15-inch EON715 powered PA speakers and the 18-inch EON718S subwoofer, EON700 systems cover the needs of today’s working musicians and sound providers.
Key Features
Custom-designed 12-inch woofer
2414H compression driver
Redesigned high-frequency horn
Power: 1,300W Peak / 650W RMS
Frequency response : 50 Hz–20 kHz (-10 dB); 60 Hz–20 kHz (-3 dB)
Max SPL : 127 dB
Dispersion : 100° H x 60° V
Audio I/Os : 2 XLR Combo, 1 XLR passthrough
Advanced dbx DSP : Automatic Feedback Suppression, ducking, 100ms speaker delay, parametric EQ
Built-in 3-channel digital mixer
Backlit color LCD screen provides easy access to functions
Universal JBL Pro Connect app control
Bluetooth 5.0 streaming and control
Durable polypropylene cabinet and metal grille
Two ergonomic handles simplify transport
Built-in pole mount and optional EON700 Universal Yoke Mount expand system configuration options
Stackable cabinets allow easy storage
Dimensions : 26.3 x 15 x 12.75 in (669 x 382 x 324 mm) (HxWxD)
Weight : 32 pounds (14.5 kg)
Shipping dimensions : 27.8 x 19.64 x 17.28 in (706 x 499 x 439 mm) (HxWxD)
Shipping weight : 40.1 pounds (18.2 kg)
Description
Specifications
System Type : 12IN Powered Loudspeaker
Woofer Model : 712G
Woofer Size : 12″
Woofer Magnet : Ferrite
Woofer Voice Coil : 2″
Tweeter Model : 2414H Compression Driver
Tweeter Size : 1″
Tweeter Magnet : Neodymium
Transducer Impedence : LF 4ohm rated, HF 8ohm rated
Max SPL : 127dB @1m/4Pi
Freq Range -10 : 50Hz – 20kHz
Freq Range -3 : 60Hz – 20kHz
Hor Dispersion : 100°
Vert Dispersion : 60°
Power Rating : 1300W peak / 650 RMS
AC power input : 100V-120V or 220V-240V
Cooling : Passive
LED indicators : 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs
Input Impedance : 50k/100k un-balanced/balanced
Input Gain : -∞to +36db
Crossover Frequency : 2 kHz
I/O : 2 XLR Combo Jacks / BT, 1 XLR M Thru
Cabinet : PP+10% Talc
Grille : 16GA perforated steel with acoustically transparent black cloth backing
Suspension / Mounting : 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes
Handles : 2, cable channel on bottom
Net Weight : 14.6kg (32.19 lbs.)
Gross Weight : 18.4kg (40.57 lbs.)
Product Dims : HxWxL 670x381x328mm (26.38×15.0x12.91 in.)
Shipping Dims : HxWxL 684x490x430mm (26.93×19.29×16.93 in.)
