Behringer WING Digital Mixer
Behringer WING 48-channel Digital Mixer
The Behringer WING 48-channel Digital Mixer that’s both ultra-powerful and incredibly easy to use. Benefit from first-class hands-on control, thanks to 24 smooth-feeling motorized 100mm faders, a capacitive touchscreen, adjustable display wheel, and touch-sensitive rotary controls. Capture sound with the utmost in quality, courtesy of eight MIDAS Pro mic preamps, while a bevy of digital I/O options provide near-limitless connectivity. Record up to 64 channels directly to dual-SD cards, use optional expansion cards to attain Dante support, or deploy the WING’s built-in 48-in/48-out USB audio interface to record straight to your DAW. Getting around the WING is a breeze, thanks to its intuitive Sources, which put the emphasis on your source audio rather than the nuts and bolts of your mix. Complete with 16 true-stereo processors with standard and classic modeled effects, the WING is a top-shelf digital console that will elevate your live sound capabilities.
Description
Behringer WING Digital Mixer Features:
- 48-stereo-channel digital mixer with 40 stereo input processing channels, as well as 8 stereo aux channels
- 28 stereo buses — 16 stereo aux buses, 8 stereo matrixes, and 4 stereo mains
- 24 smooth-feeling motorized 100mm faders in 3 separate, configurable sections
- 10.1” capacitive touchscreen, adjustable display wheel, and rotary controls provide touch-sensitive channel editing
- 8 MIDAS Pro mic preamps and MIDAS outputs ensure that you capture high-quality sound
- 3 AES50 ports provide plug-and-play remote I/O connectivity for up to 144 input and output signals
- AES50 networks are compatible with MIDAS M32 and Behringer X32 mixers
- 32-channel StageCONNECT interface for personal monitoring or analog I/O boxes
- Includes AES/EBU stereo digital I/O, 2 headphone connectors, MIDI I/O, and 4 GPIO ports
- Compatible with Behringer and MIDAS digital snakes, including the S16, S32, SD8, SD16, DL16, and DL32
- WING-LIVE card captures up to 64 channels of 32-bit/48kHz audio to a pair of SD or SDHC cards
- Optional expansion cards supply Dante support
- Built-in 48-in/48-out USB audio interface with HUI and Mackie Control DAW remote functionality
- Sources put the emphasis on your source audio rather than on your inputs and channels
- Apply names, icons, and colors to each Source for at-a-glance identification
- Each channel can be either mono, stereo, or mid-side — no channel linking required
- 16 true-stereo processors with effects from Pultec, SSL, SPL, Neve, Focusrite, dbx, Universal Audio, Elysia, and Empirical Labs
- Auto Pilot supplies fast and dependable automixing with 2 groups of gain sharing
- Dual solo/monitor buses per channel for monitoring over phones/IEM and/or floor wedges
- Support for binary and OSC communication for remote operation
- WING Co-Pilot tablet app enables you to label or set parameters while patching from the stage
Specifications:
- Type:Digital Mixer
- Channels:48 Stereo (40 x channel, 8 x aux)
- Inputs – Mic Preamps:8 x XLR-1/4″ combo (mic/line)
- Phantom Power:Yes
- Outputs – Main:8 x XLR
- Inputs – Digital:1 x XLR (AES/EBU), 3 x EtherCON (AES50 SuperMAC), 1 x XLR (StageCONNECT)
- Outputs – Digital:1 x XLR (AES/EBU), 3 x EtherCON (AES50 SuperMAC), 1 x XLR (StageCONNECT)
- Send/Return I/O:8 x 1/4″ TRS (aux in), 8 x 1/4″ TRS (aux out)
- Busses/Groups:8 x Stereo Matrix, 4 x Stereo Mains, 16 x Aux Stereo Bus
- Inserts:Dual Inserts per Bus, FX Insert Slot
- MIDI I/O:In/Out
- Data I/O:2 x Ethernet (control/audio network)
- Headphones:2 x 1/4″
- USB:1 x Type B, 1 x Type A
- Computer Connectivity:USB 2.0, 24-bit/48kHz (48 x 48)
- Remote:1 x 1/4″ (GPIO 1-2), 1 x 1/4″ (GPIO 3-4)
- I/O Expansion Slots:1 x Expansion Port (24-bit/48kHz)
- Faders:24 x 100mm Motorized
- A/D Resolution:Up to 24-bit/192kHz
- EQ Bands:6-band Parametric EQ (channel), 8-band Parametric EQ (bus), Additional EQs and Configurations
- Effects:8 x Premium FX Stereo Processors, 8 x Standard FX Stereo Processors, 5 x Variable Plug-in Slots
- Signal Processing:Full Dynamics Processing
- DAW Control:Yes (HUI, Mackie)
- Screen:10″ Capacitive Touchscreen, Adjustable Swivel
- Storage:2 x SD Card Slot (dual 32 track max)
- Power Source:Standard IEC AC cable
- Height:7.9″
- Depth:22.6″
- Width:34.3″
- Weight:52.8 lbs.
